MIL-DTL-24308/26L
REQUIREMENTS:
Dimensions and configuration: See figure 1.
Material: Cold rolled steel or corrosion resistant steel in accordance with ASTM A582/A582M.
Washer and lock washer: Cold rolled steel or corrosion resistant steel in accordance with
ASTM A582/A582M or ASTM A666.
Finish: Cold rolled steel - Yellow chromate over cadmium in accordance with SAE-AMS-QQ-P-416, or
yellow chromate over zinc in accordance with ASTM B633 or zinc nickel alloy in accordance with
ASTM B841 over a suitable underplate or Nickel fluorocarbon polymer over a suitable underplate or pure
electrodeposited aluminum in accordance with MIL-DTL-83488.
.
Corrosion resistant steel - Shall be passivated in accordance with SAE-AMS2700, type 2.
Qualification requirements: See MIL-DTL-24308/25.
F
Part or Identifying Number (PIN) example:
M24308/26
-
1
Dash number, see table I
Finish
A = Pure electrodeposited aluminum.
F = Cadmium.
K = Zinc nickel.
P = Passivated stainless steel
T = Nickel fluorocarbon polymer.
Z or No suffix = zinc.
(See MIL-DTL-24308 for disposition of stock for "No suffix" finish)
TABLE I. Dash number.
A .015
Dash no.
-1
.312
-2
.625
Changes from previous issue: The margins of this specification are marked with vertical lines to indicate
where changes from previous issue were made. This was done as a convenience only and the
Government assumes no liability whatsoever for any inaccuracies in these notations. Bidders and
contractors are cautioned to evaluate the requirements of this document based on the entire content
irrespective of the marginal notations and relationship to the last previous issue.
