INCH-POUND
MIL-DTL-24308/28E
1 December 2009
SUPERSEDING
MIL-DTL-24308/28D
25 June 2007
DETAIL SPECIFICATION SHEET
CONNECTORS, ELECTRIC, RECTANGULAR, MINIATURE,
POLARIZED SHELL, RACK AND PANEL, INSULATION
DISPLACEMENT, PIN CONTACTS, NONENVIRONMENTAL, CLASS G
This specification is approved for use by all Departments and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of this specification sheet and
MIL-DTL-24308.
SHAPE OPTIONAL
N
.510
MAX
TERMINATION
SEE NOTE
.125
VIEW
6
.115
M
L ±.015
DESIGN OPTIONAL
.510
MAX
SEE
DETAIL A
U
.232
SEE NOTE 4
FLANGE MAY BE MADE
SEE NOTE 5
SINGLE METAL
P
10°
TYP
.030
T
.329
.112
±.010
U
SINGLE METAL
.104 R TYP
WITHOUT STRAIN RELIEF
SPLIT SHELL
THICKNESS
OPTION
OPTION
ENGAGEMENT VIEW
DETAIL A
ALTERNATE FLANGE DESIGNS
FIGURE 1. Dimensions and configuration.
AMSC N/A
FSC 5935
