MIL-DTL-24308/28E
.070
.030
ALTERNATE METHOD
OF SECURING SHELL
1.030
MAX
Inches
mm
Inches
mm
Inches
mm
.010
0.25
.100
2.54
.232
5.89
.015
0.38
.104
2.64
.329
8.36
.030
0.76
.112
2.84
.422
10.72
.050
1.27
.115
2.92
.494
12.55
.070
1.78
.125
3.18
1.030
26.16
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. Unless otherwise specified tolerances are ±.005 (0.13 mm) for three place decimals and ±.01 (0.25
mm) for two place decimals.
4. Dimensions are .164 (4.17 mm) minimum full pin diameter, extension (shell sizes 1 and 2) and .155
(3.94 mm) minimum full pin diameter, extension (shell sizes 3 and 4).
5. Length for .164 and .155 pin diameter is .220 (5.59 mm) maximum.
6. Interface - Round conductor flat cable on .050 (1.27 mm) centers.
7. Mating end of contact size 20.
FIGURE 1. Dimensions and configuration - Continued.
