MIL-DTL-24308/3J
REQUIREMENTS:
The connectors shall conform to figure 1 and the specification Part or Identifying Numbers (PIN) indicated in table I.
TABLE I. Design standards. 1/
Insert
Shell
Shell
PIN
Contact
PIN
arrangement
Detail
size
Class D
PIN
Class G
reference
(see figure 1)
4/
number
3/
M24308/3-1
M24308/3-23
1
A
A-1-1
B2
M24308/3-24
2
A
A-2-1
B2
M24308/3-2
M24308/3-25
3
A
A-3-1
B2
M24308/3-3
M24308/3-4
M24308/3-26
4
A
A-4-1
B2
M24308/3-5
M24308/3-27
5
A
A-5-1
B2
2/
M24308/3-12
M24308/3-34
1
B
A-1-1
B2
M24308/3-13
M24308/3-35
2
B
A-2-1
B2
M24308/3-14
M24308/3-36
3
B
A-3-1
B2
M24308/3-15
M24308/3-37
4
B
A-4-1
B2
M24308/3-16
M24308/3-38
5
B
A-5-1
B2
2/
M24308/3-17
M24308/3-39
M24308/3-18
M24308/3-40
2
D
A-2-1
B2
M24308/3-19
M24308/3-41
3
D
A-3-1
B2
M24308/3-20
M24308/3-42
4
D
A-4-1
B2
M24308/3-21
M24308/3-43
5
D
A-5-1
B2
1/ These connectors mate with connectors specified in MIL-DTL-24308/1, MIL-DTL-24308/2, and MIL-DTL-24308/23.
2/ PINs M24308/3-12 through M24308/3-16 and M24308/3-34 through M24308/3-38 are inactive for new design,
see M24308/3-17 through M24308/3-21 and M24308/3-39 through M24308/3-43.
3/ For insert arrangement see MIL-DTL-24308, Appendix A.
4/ For contact see MIL-DTL-24308, Appendix B.
PIN: Consists of the letter M, the basic number of the specification sheet, and a dash number compiled from the
code.
PIN example:
M24308/3
-35
F
Specification sheet number
Data sheet number from table
Finish: For class G:
A = Pure electrodeposited aluminum.
F = Cadmium .
K = Zinc nickel.
T = Nickel Fluorocarbon Polymer.
Z or No suffix = zinc. (See MIL-DTL-24308 for disposition of stock for "No suffix" finish)
For class D:
Class D connectors have a nickel finish, no suffix is required.
4
