MIL-DTL-24308/6R
PIN: Consists of the letter M, the basic number of the specification sheet, and a dash number compiled from the
code.
PIN example:
M24308/6
-491
F
Specification sheet number
Data sheet number from table I
Finish: For class N:
A = Pure electrodeposited aluminum
F = Cadmium (Navy-SH prohibits the use of cadmium finished connectors for shipboard application)
K = Zinc nickel
P = Passivated stainless steel
T = Nickel Fluorocarbon Polymer
Z = Zinc
For class M: Class M connectors have a gold finish, no suffix is required.
TABLE II. Shell supersession data.
Shell detail
Superseded MS sheet
(see figure 1)
Detail A
MS18270-1 through -6
Detail B
MS18270-7 through -12
Detail C
MS18270-13 through -18
Detail D
MS18270-19 through -24
TABLE III. Contact supersession data.
Contact
Superseded contact
(see table I)
M39029/57-662
M39029/57-354
M39029/63-656
M39029/63-368
CHANGES FROM PREVIOUS ISSUE: The margins of this specification are marked with asterisks to indicate where
changes from the previous issue were made. This was done as a convenience only and the Government assumes
no liability whatsoever for any inaccuracies in these notations. Bidders and contractors are cautioned to evaluate the
requirements of this document based on the entire content irrespective of the marginal notations and relationship to
the last previous issue.
Referenced documents. In addition to MIL-DTL-24308, this document references the following:
MIL-DTL-24308/7
MIL-DTL-24308/8
8
