MIL-DTL-25955 Connectors, Electrical, Environment Resisting, Miniature, With Snap-In ContactsThis specification covers miniature electrical connectors, plugs and receptacles, of an environment resisting class with snap-in contacts and receptacles of identical mating dimensions of a hermetically sealed class with non-removable contacts.

Pages 1 - - 2 - 3 - 4 - 5 - 6 - 7 - 8|||9 - 10 - 11 - 12 - 13 - 14 - 15|||

MIL-DTL-25955A

Contact

� .001

� .015 � .016

size

max

min

max

min

.040

.085

.067

.042

.115

.082

.321

.109

(1.016)

(2.159) (1.702) (1.067) (2.921) (2.083) (8.153) (2.768)

Inches

.005

.127

.007

.178

.008

.203

.012

.305

.020

.508

.060

1.524

NOTES:

1. Socket engaging end is necessary. Socket termination is identical to pin termination.

2. Insert contacting and snap-in surfaces as necessary.

3. Dimensions are in inches.

FIGURE 1. Contacts.
