MIL-DTL-2726/15C
REQUIREMENTS
Dimensions and configurations: See figures 1 and 2.
Effectiveness of enclosure: Watertight in accordance with MIL-STD-108.
Enclosure assembly: See table I.
Receptacle unit: See table l.
Material: For symbol number 1146.3, box and cover with receptacle unit, integral, shall be of
molded plastic in accordance with ASTM-D5948 type MAI-60.
Cap assembly: MIL-DTL-2726/13, Part or Identifying Number (PIN): M2726/13 - 001.
Mating plug: MIL-DTL-2726/2, PIN M2726/2 - 001.
Electrical rating: 50 ampere, 250 volt, direct current.
PIN: See table I.
TABLE I. Assembly parts.
PIN
Symbol number
Box
Cover
Receptacle unit
M24142/5-002
M24142/5-0O2
M2726/8-001
M2726/15-001
1146.1
(metal)
(metal)
(metal housing)
M24142/5-002
M24142/5-002
M2726/8-002
M2726/15-002
1146.2
(metal)
(metal)
(plastic)
Molded plastic (see
(see ASTM-D5948,
M2726/18-002
M2726/15-003
1146.3
ASTM-D5948, MAI-60)
MAI-60)
(integral with cover)
M2726/15-004
------
------
------
See figure 2
Verification
Verification shall be as specified in MIL-DTL-2726 and table I herein. The first article and
conformance inspections shall consist of the inspections as specified in table II, in the order shown.
