MIL-DTL-2726-16 Receptacle, Electrical, Enclosed, 4 - Pin Grounded, 40 - Ampere, 450 - Volt, Alternating Current \(Symbol Nos. 1147.1, 1147.2 And 1147.3\)

Pages 1 - 2 - 3 - 4 - 5 - 6

MIL-DTL-2726/16B

Inches

.094

2.39

.188

4.77

.38

9.6

1.125

28.57

1.250

31.75

2.812

71.42

3.312

84.12

6.125

155.57

NOTES:

Dimensions are in inches.

Metric equivalents are given for information only.

Unless otherwise specified, tolerances are � .016 (0.41mm) and � .5� on angles.

Supersedes: Drawing 815 -1197213, symbol 1147.

Mounting bolt: .38 - 16 HEX HD.

FIGURE 1. Receptacle (symbol 1147.1 shown) � Continued.
