MIL-DTL-2726/16B
REQUIREMENTS
Dimensions and configurations: See figures 1 and 2.
Effectiveness of enclosure: Watertight in accordance with MIL-STD-108.
Enclosure assembly: See table I.
Receptacle assembly: See table I.
Cap assembly: MIL-DTL-2726/13, Part or Identifying Number (PIN) M2726/13-001.
Material: For symbol number 1147.3, the box shall be molded plastic, in accordance with
ASTM-D5948 type MAI-60, (see table I).
Mating plug: MIL-DTL-2726/3, PIN M2726/3-001.
Electrical rating: 40-ampere, 450-volt, alternating current, 60-hertz.
PIN: See table I.
TABLE I. Assembly parts.
PIN
Symbol number
Box
Cover
Receptacle unit
M24142/5-002
M24142/5-002
M2726/9-001
M2726/16-001
1147.1
(metal)
(metal)
(metal housing)
M24142/5-002
M24142/5-002
M2726/9-002
M2726/16-002
1147.2
(metal)
(metal)
(plastic)
M2726/9-002
Molded plastic
(see ASTM-D5948
(integral with
M2726/16-003
1147.3
(see ASTM-D5948
MAI-60)
cover)
MAI-60)
M2726/16-004
----------
----------
----------
See figure 2
VERIFICATION
Verification shall be as specified in MIL-DTL-2726 and table lI herein. The first article and
conformance inspections shall consist of the inspections as specified in table Il, in the order
shown.
