MIL-DTL-2726/17C
REQUIREMENTS
Dimensions and configurations: See figures 1 and 2.
Effectiveness of enclosure: Watertight in accordance with MIL-STD-108.
Enclosure assembly: See table I.
Receptacle assembly: See table I.
Cap assembly: MIL-DTL- 2726/13, Part or Identifying Number (PIN) M2726/13 - 001.
Material: For symbol number 1148.3, the box and cover with receptacle unit integral, shall
be of molded plastic, in accordance with ASTM-D5948 type MAI-60.
Mating plug: MIL- DTL-2726/6, PIN M2726/6-001.
Electrical rating: 40-ampere, 125-volt, alternating current, 60-hertz.
PIN: See table I.
TABLE I. Assembly parts.
PIN
Symbol number
Box
Cover
Receptacle unit
M24142/5-002
M24142/5-002
M2726/12-001
M2726/17-001
1148.1
(metal)
(metal)
(metal housing)
M24142/5-002
M24142/5-002
M2726/12-002 (plastic)
M2726/17-002
1148.2
(metal)
(metal)
Molded plastic (see
(see ASTM-D5948-
M2726/12-002
M2726/17-003
1148.3
ASTM-D5948, MAI-60)
MAI-60 )
(integral with cover)
M2726/17-004
--------
------
------
See figure 2
Verification
Verification shall be as specified in MIL-DTL-2726 and table Il herein. The first article and
conformance inspections shall consist of the inspections as specified in table lI, in the order shown.
