INCH-POUND
MIL-DTL-2726/19D
22 April 2014
SUPERSEDING
MIL-DTL-2726/19C
20 February 2007
DETAIL SPECIFICATION SHEET
RECEPTACLE WITH SWITCH, ELECTRICAL, 30 - AMPERE, 450 - VOLT, ALTERNATING CURRENT,
60-HERTZ, 3 - PHASE, INTERLOCKING, GROUND (SYMBOL NO. 915.1)
Reactivated after 27 November 2002 and may be used for new and
existing designs and acquisitions.
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall
consist of this specification sheet and MIL-DTL-2726.
FIGURE 1. Dimensions and configurations.
AMSC N/A
FSC 5935
