MIL-DTL-2726/22B
REQUIREMENTS
Dimensions and configurations: See figure 1.
Effectiveness of enclosure: Submersible (15-foot) in accordance with MIL-STD-108.
Connectors: Burndy Quicklug, type Q2B (250 MCM - 300 MCM), or equal.
Mating plug: Drawing 9-S-5259-L, type M.
Enclosure assembly: In accordance with MIL-E-24142/6, Part or Identifying Number (PIN)
M24142/6-003.
Electrical rating: 200 - ampere, direct current.
PIN: M2726/22-001 (assembly), M2726/22-002 (rapid coupling).
Identification and warning plate shall be furnished.
Caps shall be furnished.
Verification
Verification shall be as specified in MIL-DTL-2726 and table I herein. The first article and
conformance inspections shall consist of the inspections as specified in table I, in the order shown.
TABLE I. First article and quality conformance inspection.
First
Conformance
Inspection
article
Examination
X
X
Insulation resistance
X
X
Dielectric withstanding voltage
X
X
Current load
X
X
Vibration
X
Shock
X
Effectiveness of Enclosure
X
X
Dielectric withstanding voltage
X
Marginal notations are not used in this revision to identify changes with respect to the previous issue due
to the extent of the changes.
Referenced documents. In addition to MIL-DTL-2726, this document references the following:
MIL-E-24142/6
MIL-STD-108
4
