MIL-DTL-2726/23B
Electrical rating: 100-ampere, 250-volt, direct current.
PIN: M2726/23-001 (assembly), M2726/23-002 (receptacle fitting).
VERIFICATION
Verification shall be as specified in MIL-DTL-2726 and table I herein. The first article and
conformance inspections shall consist of the inspections as specified in table I, in the order shown.
TABLE I. First article and quality conformance inspection.
First
Conformance
Inspection
article
Examination
X
X
Insulation resistance
X
X
Dielectric withstanding voltage
X
X
Contact resistance
X
X
Current load
X
Endurance
X
Salt spray
X
Contact resistance
X
Vibration
X
Shock
X
Effectiveness of enclosure
X
X
Dielectric withstanding voltage
X
Marginal notations are not used in this revision to identify changes with respect to the previous issue due
to the extent of the changes.
Referenced documents. In addition to MIL-DTL-2726, this document references the following:
ASTM-D5948
MIL-I-24768/1
MIL-PRF-900
MIL-DTL-2726/46
MIL-STD-108
SAE-AS28775
CONCLUDING MATERIAL
Custodians:
Preparing activity
Navy - SH
DLA - CC
DLA - CC
(Project 5935-4617-016)
NOTE: The activities listed above were interested in this document as of the date of this document.
Since organizations and responsibilities can change, you should verify the currency of the information
above using the ASSIST Online database at https://assist.daps.dla.mil.
