MIL-DTL-2726/25B
Mating plug: MIL-DTL-2726/24, PIN M2726/24-001.
Test cable: MIL-DTL-24643 and MIL-DTL-24643/3.
Design: Binding head screws may be used. Individual pathways through the contact Insulation shall
be provided to each contact, of ample size to accept the insulated conductors.
PIN: M2726/25-001.
Electrical rating: 25-ampere, 500-volt, alternating current, 60 hertz.
Cap for maintaining submersible integrity shall be furnished.
Verification
Verification shall be as specified in MIL-DTL-2726 and table I herein. The first article and
conformance inspections shall consist of the inspections as specified in table I, in the order shown.
TABLE I. First article and quality conformance inspection.
First
Conformance
Inspection
article
Examination
X
X
Insulation resistance
X
X
Dielectric withstanding voltage
X
X
Contact resistance
X
X
Endurance
X
Salt spray
X
Contact resistance
X
Current load
X
Vibration
X
Shock
X
Effectiveness of Enclosure
X
X
Dielectric withstanding voltage
X
Rockwell hardness
X
Marginal notations are not used in this revision to identify changes with respect to the previous issue due
to the extent of the changes.
Referenced documents. In addition to MIL-DTL-2726, this document references the following:
ASTM-D5948
ASTM-F1836M
MIL-DTL-24643
MIL-DTL-24643/3
MIL-DTL-2726/24
MIL-I-24768/8
MIL-S-19622/3
MIL-S-19622/19
MIL-STD-108
3
