INCH-POUND
MIL-DTL-2726/40B
20 October 2006
SUPERSEDING
MIL-R-2726/40A(SH)
3 July 1986
DETAIL SPECIFICATION SHEET
RECEPTACLE CHANNEL, ELECTRICAL, 15 - AMPERE, 125 - VOLT,
BLADED TYPE, GROUNDED (SYMBOL NO. 730.4)
Inactive for new design after 28 June 1999.
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of this
specification sheet and MIL-DTL-2726.
Inches
mm
5.21
.205
5.38
.212
6.22
.245
6.42
.255
6.73
.265
7.22
.285
8.38
.330
8.89
.350
10.28
.405
10.79
.425
11.76
.463
12.01
.473
12.70
.500
.575
14.60
.595
15.11
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. Unless otherwise specified, tolerances are ± .016 (0.41mm).
FIGURE 1. Dimensions and configuration.
AMSC N/A
FSC 5935
