MIL-DTL-2726/46B
REQUIREMENTS
Dimensions and configurations: See figure 1.
Effectiveness of enclosure: Watertight in accordance with MIL-STD-108 when coupled with mating
receptacle.
Material: Plug housing brass; cap brass; contact holder in accordance with
ASTM-D5948 type MAI-60.
Strain relief: 40 pounds.
Contact hardness: Minimum of Rockwell 60B.
Stuffing tube in accordance with MIL-S-19622/3, Part or Identifying Number (PIN) shall be furnished
with the plug.
Packing assembly: MIL-S-19622/21, PIN M19622/21-003.
Mating receptacle: MIL-DTL-2726/23, PIN M2726/23-001.
Test cable: In accordance with MIL-DTL-24643 and MIL-DTL-24643/3.
PIN: M2726/46-001.
Electrical rating: 100-ampere, 250-volt, direct current.
VERIFICATION
Verification shall be as specified in MIL-DTL-2726 and table I herein. The first article and
conformance inspections shall consist of the inspections as specified in table I, in the order shown.
TABLE I. First article and quality conformance inspection.
First
Conformance
Inspection
article
Examination
X
X
Insulation resistance
X
X
Dielectric withstanding voltage
X
X
Contact resistance
X
X
Endurance
X
Salt spray
X
Contact resistance
X
Current load
X
Vibration
X
Shock
X
Effectiveness of enclosure
X
X
Dielectric withstanding voltage
X
Mechanical abuse
X
Strain relief
X
Rockwell hardness
X
3
