MIL-DTL-2726/50D
Examination and tests:
Requirements for first article and quality conformance, as shown below, shall be in accordance with
MIL-R-2726. Examinations and tests shall be performed in the order shown (see table I).
Examination: Visual and dimensional examination shall meet the requirements for materials, design
and construction, performance, marking and workmanship indicated in MIL-R-2726.
Tests: The following tests shall be required.
TABLE I. First article and quality conformance inspection.
Test per MIL-R-2726
First article
Quality conformance
Insulation resistance
X
X
Dielectric withstanding voltage
X
X
Contact resistance, plugs and receptacles
X
X
Endurance
X
Salt spray
X
Contact resistance, plugs and receptacles
X
Current load
X
Vibration
X
Shock
X
Effectiveness of enclosure
X
X
Dielectric withstanding voltage
X
Mechanical abuse
X
Ball drop impact
X
Strain relief
X
Note: Marginal notations are not used in this revision to identify changes with respect to the previous
issue due to the extent of the changes.
CONCLUDING MATERIAL
Custodians:
Preparing activity:
Navy SH
DLA - CC
DLA CC
(Project 5935-4424-003)
9
