MIL-DTL-2726/69C
REQUIREMENTS
Dimensions and configurations: See figure 1.
Enclosure housing and cover shall be of synthetic rubber compound, neoprene or nitrile, commercial
yellow. Durometer hardness 62-1/2 ± 2-1/2.
Plug shall conform to W-C-596/13, Part or Identifying Number (PIN) WC596/13-3 for 3-wire grounding
yellow.
Cable: Type S0#12/3 conductor, 25 feet long ± 6 inches, outer sheath yellow. Conductors shall be
color coded black, white, and green.
Receptacle shall conform to W-C-596/11 PIN WC596/11-1. The ground contact blade shall be nickel-
plated. Insulation shall be polycarbonate. The power contacts shall not be nickel-plated.
Mating plug shall be W-C-596/13-3 (No. 5276).
Cable clamps: Strain relieved cable clamps shall be of polycarbonate.
Electrical rating: 15-ampere, 125-volt, alternating current, 60-hertz.
PIN: M2726/69-001.
VERIFICATION
Verification shall be as specified in MIL-DTL-2726 and table I herein. The first article
and conformance inspections shall consist of the inspections as specified in table I,
in the order shown.
TABLE I. First article and conformance inspection.
Inspection
First article
Conformance
Examination
X
X
Endurance
X
Ground contact resistance
X
X
Insulation resistance
X
X
Dielectric withstanding voltage
X
X
Current load
X
Vibration
X
Shock
X
Mechanical abuse
X
Leakage current
X
X
Marginal notations are not used in this revision to identify changes with respect to the previous issue due
to the extensiveness of the changes.
