MIL-DTL-2726/72C
REQUIREMENTS
Dimensions and configuration: See figure 1.
Strain relief (connector assembly): 40 pounds.
Molded connector female: In accordance with W-C-596/11 Part or Identifying Number (PIN):
WC596/11-1. The female grounding contact shall be nickel-plated.
Molded plug, male: In accordance with W-C-596/17, PIN WC596/17-1. The plug body shall be
firmly bonded to the cable.
Cable: In accordance with type C0-03H0F (3/14) of MIL-DTL-3432.
Mating plug, male: In accordance with W-C-596/13, PIN WC596/13.
Mating receptacle: MIL-DTL-2726/70, PIN M2726/70-001, or MIL-DTL-2726/71, PIN M2726/71-001
(not furnished).
Intended use: To permit test instruments having 60 to 400-hertz (Hz) range (and wired with 60-Hz
plug) to be connected to 400-Hz outlet.
Electrical rating: 15-ampere, 125-volt, alternating current, 60 to 400-Hz.
PIN: M2726/72-001.
VERIFICATION
Verification shall be as specified in MIL-DTL-2726 and table I herein. The first article and conformance
inspections shall consist of the inspections as specified in table I, in the order shown.
TABLE I. First article and conformance inspection.
Inspection
First article
Conformance
Examination
X
X
Insulation resistance
X
X
Dielectric withstanding voltage
X
X
Endurance
X
X
Strain relief
Mechanical abuse
X
Ball drop impact
X
Current load
X
Marginal notations are not used in this revision to identify changes with respect to the previous issue due
to the extensiveness of the changes.
2
