INCH-POUND

MIL-DTL-28731/36C

15 March 2004

SUPERSEDING

MIL-C-28731/36B

4 June 1985

DETAIL SPECIFICATION SHEET

CONNECTOR, ELECTRICAL, CONTACT FORK TYPE,

WRAPPOST REMOVABLE (3.0 AMPERES)

This specification is approved for use by all Departments

and Agencies of the Department of Defense.

The requirements for acquiring the product described herein shall consist of this specification sheet and

MIL-DTL-28731.

Inches

1.83

.072

0.03

.001

1.93

.076

0.038

.0015

1.98

.078

0.08

.003

2.41

.095

0.38

.015

5.72

.225

0.41

.016

9.27

.365

0.64

.025

29.59

1.165

1.24

.049

FIGURE 1. Contact, fork type, wrappost removable.

AMSC N/A

FSC 5935
