MIL-DTL-28840/24D
Shell size
A
B
C
D
F
designator
dia
dia
radius
(see note 1)
.766 (19.46)
1.039 (26.39)
.130 (3.30)
.151 (3.84)
.760 (19.30)
A (11)
.740 (18.80)
.750 (19.05)
1.023 (25.98)
.110 (2.79)
.131 (3.33)
.891 (22.63)
1.154 (29.31)
.130 (3.30)
.151 (3.84)
.853 (21.67)
B (13)
.833 (21.16)
.875 (22.22)
1.138 (28.90)
.110 (2.79)
.131 (3.33)
1.078 (27.38)
1.274 (32.36)
.130 (3.30)
.151 (3.84)
.978 (24.84)
C (15)
.958 (24.33)
1.062 (26.97)
1.258 (31.95)
.110 (2.79)
.131 (3.33)
1.025 (26.04)
1.141 (28.98)
1.399 (35.53)
.130 (3.30)
.166 (4.22)
D (17)
1.005 (25.53)
1.125 (28.58)
1.383 (35.13)
.110 (2.79)
.146 (3.71)
1.338 (33.98)
1.524 (38.71)
.130 (3.30)
.182 (4.62)
1.150 (29.21)
E (19)
1.130 (28.70)
1.312 (33.32)
1.508 (38.30)
.110 (2.79)
.162 (4.11)
1.516 (38.51)
1.734 (44.04)
.130 (3.30)
.198 (5.03)
1.291(32.79)
F (23)
1.271 (32.28)
1.500 (38.10)
1.718 (43.64)
.110 (2.79)
.178 (4.52)
1.641 (41.68)
1.834 (46.58)
.157 (3.99)
.198 (5.03)
1.402 (35.61)
G (25)
1.382 (35.10)
1.625 (41.28)
1.818 (46.18)
.137 (3.48)
.178 (4.52)
1.891 (48.03)
2.154 (54.71)
.157 (3.99)
.229 (5.82)
1.578 (40.08)
H (29)
1.558 (39.57)
1.875 (47.62)
2.138 (54.30)
.137 (3.48)
.209 (5.31)
2.078 (52.78)
2.344 (59.54)
.183 (4.65)
.229 (5.82)
1.744 (44.30)
J (33)
1.724 (43.79)
2.062 (52.37)
2.328 (59.13)
.163 (4.14)
.209 (5.31)
NOTES:
1. Shell sizes are provided within parentheses for information and are not a part of the designator.
2. Dimensions are in inches.
3. Metric equivalents are given for information only.
FIGURE 1. Dimensions and configurations - Continued.
