MIL-DTL-28840/24D
REQUIREMENTS:
Dimensions and configuration: See figure 1.
Material types:
Type A, fluorinated silicone: Material shall be in accordance with SAE-AMS-R-25988 (50 shore).
Color: Blue.
Type B, EMI shielding gasket: Material shall be rubber in accordance with A-A-59588, class 2, grade
30, embedded with MonelTM wires in accordance with QQ-N-281.
Part or Identifying Number (PIN) example:
M28840/
24
G
A
Military designator
Specification sheet number
Shell size designator
Material designator
A Fluorinated silicone
B EMI shielding
Changes from previous issue. The margins of this specification are marked with vertical lines to indicate
where changes from the previous issue were made. This was done as a convenience only and the
Government assumes no liability whatsoever for any inaccuracies in these notations. Bidders and
contractors are cautioned to evaluate the requirements of this document based on the entire content
irrespective of the marginal notations and relationship to the last previous issue.
Referenced documents. In addition to MIL-DTL-28840, this document references the following:
A-A-59588
QQ-N-281
SAE-AMS-R-25988
CONCLUDING MATERIAL
Custodians:
Preparing activity:
Army - AT
DLA - CC
Navy - EC
Air Force - 85
DLA - CC
(Project 5935-2013-122)
Review activities:
Army AV, MI
Navy - SH
Air Force 99
NASA NA
NOTE: The activities listed above were interested in this document as of the date of this document.
Since organizations and responsibilities can change, you should verify the currency of the information
above using the ASSIST Online data at https://assist.dla.mil.
