MIL-DTL-28840/26E
Assembly
Connector
Backshell
A
Cable entry
Designator
(PIN)
receptacle
assembly
(see note 1)
(see note 6)
(PIN)
(PIN)
max
min
(see note 6)
(see note 6)
.938
.625
G (25)
M28840/26*G*A***
M28840/16*G***
M28840/616**
(23.83) (15.88)
1.188
.812
G (25)
M28840/26*G*B***
M28840/16*G***
M28840/617**
(30.18) (20.62)
1.250
.875
G (25)
M28840/26*G*C***
M28840/16*G***
M28840/618**
(31.75) (22.23)
1.380
1.000
G (25)
M28840/26*G*D***
M28840/16*G***
M28840/619**
(35.05) (25.40)
1.188
.812
H (29)
M28840/26*H*A***
M28840/16*H***
M28840/620**
(30.18) (20.62)
1.380
1.000
H (29)
M28840/26*H*B***
M28840/16*H***
M28840/621**
(35.05) (25.40)
1.380
1.000
J (33)
M28840/26*J*A***
M28840/16*J***
M28840/622**
(35.05) (25.40)
1.625
1.250
J (33)
M28840/26*J*B***
M28840/16*J***
M28840/623**
(41.28) (31.75)
FIGURE 1. Dimensions and configuration Continued.
