MIL-DTL-28840/26E
Designator
Assembly
Connector
Backshell
B
E
L
(see note 1)
number
receptacle
Assembly
thread
ref
max
(PIN)
(PIN)
(PIN)
class
(see note 6)
(see note 6)
(see note 6)
2B
1.750
7.625
G (25)
M28840/26*G*A***
M28840/16*G***
M28840/616**
1.625-.1P.2L-D.S.
(44.45) (193.68)
2.093
8.312
G (25)
M28840/26*G*B***
M28840/16*G***
M28840/617**
1.625-.1P.2L-D.S.
(53.16) (211.12)
2.093
8.312
G (25)
M28840/26*G*C***
M28840/16*G***
M28840/618**
1.625-.1P.2L-D.S.
(53.16) (211.12)
2.343
8.312
G (25)
M28840/26*G*D***
M28840/16*G***
M28840/619**
1.625-.1P.2L-D.S.
(59.51) (211.12)
2.093
8.312
H (29)
M28840/26*H*A***
M28840/16*H***
M28840/620**
1.812-.1P.2L-D.S.
(53.16) (211.12)
2.343
8.312
H (29)
M28840/26*H*B***
M28840/16*H***
M28840/621**
1.812-.1P.2L-D.S.
(59.51) (211.12)
2.343
8.312
J (33)
M28840/26*J*A***
M28840/16*J***
M28840/622**
2.000-.1P.2L-D.S.
(59.51) (211.12)
2.750
8.625
J (33)
M28840/26*J*B***
M28840/16*J***
M28840/623**
2.000-.1P.2L-D.S.
(69.85) (219.08)
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. Shell sizes are provided within parentheses for information and are not a part of the designator.
4. Dimensions apply after plating.
5. Normal mating key position shown. Alternate key positions in accordance with MIL-DTL-28840.
6. Assembly shall be made of a connector and backshell of the same material.
FIGURE 1. Dimensions and configuration Continued.
