MIL-DTL-3655/1C
Item
Description
Material
Quantity
1
Nut
Brass
1
2
Body
Brass
1
3
Gasket
Silicone Rubber
1
4
Clamp
Brass
1
5
Pin
Beryllium copper
1
6
Sleeve
Brass
1
7
Coupling nut
Brass
1
8
Spring
Phosphor bronze
1
9
Gasket
Silicone rubber
1
10
Insulator
Plastic
1
11
Center contact
Brass
2
Inches mm
Inches mm
Inches mm
Inches mm
Inches mm
.001 0.03
.059 1.50
.219 5.56
.535 3.59
.687 17.45
.002 0.05
.061 1.55
.229 5.82
.560 14.22
.6875 17.46
.003 0.08
.062 1.57
.250 6.35
.565 14.35
.697 17.70
.005 0.13
.0625 1.59
.295 7.49
.573 14.55
.699 17.75
.007 0.18
.070 1.78
.298 7.57
.575 14.61
.737 18.72
.010 0.25
.087 2.21
.350 8.89
.585 14.86
.740 18.80
.015 0.38
.092 2.34
.375 9.53
.593 15.06
.750 19.05
.018 0.46
.093 2.36
.420 10.67
.600 15.24
.765 19.43
.020 0.51
.095 2.41
.437 11.10
.605 15.37
.843 21.41
.025 0.64
.109 2.77
.438 11.13
.625 15.88
.875 22.23
.028 0.71
.125 3.18
.440 11.18
.628 15.95
1.500 38.10
.030 0.76
.138 3.51
.465 11.81
.635 16.13
1.572 39.93
.031 0.79
.156 3.96
.495 12.57
.636 16.15
1.750 44.45
.045 1.14
.180 4.57
.500 12.70
.644 16.36
.053 1.35
.187 4.75
.533 13.54
.670 17.02
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. Wrench flats are to accommodate standard wrench openings in
accordance with FED-STD-H28, appendix 10.
4. Unless otherwise specified, the tolerance is ±. 005 (0.13 mm).
5. All undimensioned pictorial configurations are for reference purposes only.
FIGURE 1. Type UG-421B/U, connector, plug, electrical Continued.
