MIL-DTL-38999/10B
DETAIL A
Dimensions
X
Y
Shell
R
S
T
(TYP)
(TYP)
size
BSC
max
dia
+.010
-.005
82�
118�
8
.297
.828
72�
128�
10
.3595
.954
68�
132�
12
.406
1.047
66�
134�
14
.453
1.141
.120
70�
130�
16
.4845
1.234
70�
130�
18
.531
1.328
70�
130�
20
.578
1.453
74�
126�
22
.625
1.578
74�
126�
24
.6875
1.703
.147
FIGURE 1. Dummy receptacle, finishes B and X - Continued.
2
