MIL-DTL-38999/10B
REQUIREMENTS:
Dimensions and configuration: See figure 1.
Interface dimensions shall conform to MIL-DTL-38999, except as noted.
Material:
Shell: Aluminum alloy as specified in MIL-DTL-38999 with finishes B or X.
Sealing gasket: Non-corrosive silicone or fluorosilicone elastomer.
This receptacle mates with MS27473, MS27480, MS27484 and MS27500.
Fits all polarization positions.
Part or Identifying Number (PIN) example:
M38999/10
10
B
Specification sheet number
Shell size
Finish
NOTE: The term PIN is equivalent to the term (part number, identification number, and type designator)
which was previously used in this specification.
Qualification:
Qualification shall consist of the dynamic salt spray test, altitude immersion, coupling torque, coupling
pin strength, and visual and mechanical inspection as specified in MIL-DTL-38999, conducted on two
samples of each shell size.
Changes from previous issue. Marginal notations are not used in this revision to identify changes with
respect to the previous issue, due to the extent of the changes.
Referenced documents. In addition to MIL-DTL-38999, this document references the following:
MIL-DTL-27599
MS27473
MS27480
MS27484
MS27500
