MIL-DTL-38999/24J
Dimensions
External bending
Shell
Shell
G
J
P
S
W
Recommended
± 0.4
moment
size
size
Thread
+ 0.0 + 0.6
+ 0.9
O-ring
Classes J and M
code
- 0.71 - 0.0
- 0.1
SAE-AS3582
(NewtonMeters)
(see note 4)
9
A
M17x1-6g 0.100R 1.5 14.1 27.0 2.2 (.087)
-019
8.5
(.059) (.555) (1.063)
11
B
M20x1-6g 0.100R 1.5 14.1 31.8 2.2 (.087)
-022
14.1
(.059) (.555) (1.252)
13
C
M25x1-6g 0.100R 1.5 14.1 34.9 2.2 (.087)
-024
19.8
(.059) (.555) (1.374)
15
D
M28x1-6g 0.100R 1.5 14.1 38.1 2.2 (.087)
-026
28.2
(.059) (.555) (1.500)
17
E
M32x1-6g 0.100R
---
14.1 41.3 2.2 (.087)
-028
36.7
(.555) (1.626)
(see note 2)
19
F
M35x1-6g 0.100R
---
14.1 46.0 3.0 (.118)
-128
45.2
(.555) (1.811)
21
G
M38x1-6g 0.100R
---
14.1 49.2 3.0 (.118)
-130
53.7
(.555) (1.937)
23
H
M41x1-6g 0.100R 1.5 14.1 52.4 3.0 (.118)
-132
62.1
(.059) (.555) (2.063)
25
J
M44x1-6g 0.100R 1.5 14.1 55.6 3.0 (.118)
-134
73.4
(.059) (.555) (2.189)
NOTES:
1.
Dimensions are in millimeters. Inch equivalents are given for information only.
2.
Modified major diameter: 31.95 - 31.80.
3.
Panel thickness: 3.2 - 1.58.
4.
Alternate O-ring material may be SAE-AMS3325 (fluorosilicone O-ring). Fluorosilicone materials
have greater hydrocarbon fluid resistance than silicone materials and should be considered for
applications where resistance to hydrocarbon fluids is critical.
5.
C and J dimensions define feature required for proper fit in type E panel.
6.
F diameter defines thread start.
7.
This dimension applies to sizes 17, 19, and 21 only (C and G diameters are the same).
8.
Countersink may be incorporated to accept accessory configuration in accordance with
MIL-DTL-38999.
9.
Classes J and M should not be used when critical connector to panel bonding (below 10 millivolts)
is required.
10. For classes J and M only, overall shell length is increased to 33.0 mm (1.300 in) max.
FIGURE 1. Receptacle, classes F, G, J, K, M, P, R, S, T, W, X and Z - Continued.
