MIL-DTL-38999/24J
REQUIREMENTS:
Dimensions and configuration: See figure 1. Interface dimensions shall be in accordance with
MIL-DTL-38999.
This connector mates with MIL-DTL-38999/26.
O-ring and MIL-DTL-38999/28 nut shall be provided with jam-nut receptacle.
For insert arrangements: See MIL-STD-1560.
Connector accessories: See SAE-AS85049.
Part or Identifying Number (PIN) example:
D38999/
24
W
A
35
P
N
DoD number prefix
Specification sheet number
Class
Shell size code
Insert arrangement
Contact style
Polarizing positions
N is required for normal position
Class F is not for Navy use and is inactive for Air Force new design use.
NOTE: The term PIN is equivalent to the term (part number, identification number, and type designator)
which was previously used in this specification.
Qualification required: The activity responsible for the qualified products list for this specification sheet is
DLA Land and Maritime-VQ, P.O. Box 3990, Columbus, Ohio 43218-3990.
Changes from previous issue. The margins of this specification are marked with vertical lines to indicate
where changes from the previous issue were made. This was done as a convenience only and the
Government assumes no liability whatsoever for any inaccuracies in these notations. Bidders and
contractors are cautioned to evaluate the requirements of this document based on the entire content
irrespective of the marginal notations and relationship to the last previous issue.
