MIL-DTL-38999/30C
mm
Inches
mm
Inches
0.8
.03
46.1
1.81
6.3
.25
60.0
2.36
9.5
.37
Shell
Shell
A
B
C
VV
Backshell extender
size
size
torque
max
min
max
thread
code
11
B
46.9
25.5
25.0
M15x1.0-6g 0.100R
(1.85)
(1.00)
(.98)
13
C
50.1
29.9
29.4
M18x1.0-6g 0.100R
(1.97)
(1.18)
(1.16)
15
D
52.8
33.0
32.5
M22x1.0-6g 0.100R
(2.08)
(1.30)
(1.28)
17
E
56.0
36.2
35.7
M25x1.0-6g 0.100R
5.6 Newton-meters
(2.20)
(1.43)
(1.41)
min
19
F
59.2
39.0
38.5
M28x1.0-6g 0.100R
(2.33)
(1.54)
(1.52)
21
G
62.8
42.2
41.7
M31x1.0-6g 0.100R
(2.47)
(1.66)
(1.64)
23
H
65.9
45.4
44.9
M34x1.0-6g 0.100R
(2.59)
(1.79)
(1.77)
25
J
68.7
48.5
48.0
M37x1.0-6g 0.100R
(2.70)
(1.91)
(1.89)
NOTES:
1. Dimensions are in millimeters. Inch equivalents in parentheses are given for information only.
2. EMI grounding feature required on this connector.
3. Dimension indicates clearance required for proper operation. Connector must be capable of
accepting and functioning with applicable SAE-AS85049 accessories.
4. Backshell extender is factory installed but may be removed for serviceability if necessary. If
removed the extender must be reassembled and torqued to specified value for proper operation
of connector.
FIGURE 1. Plug, classes F, G, J, K, M, R, S, W, T, X and Z - Continued.
