MIL-DTL-38999/30C
REQUIREMENTS:
Dimensions and configuration: See figure 1. Interface dimensions shall conform to MIL-DTL-38999.
This connector mates with MIL-DTL-38999/20, /21, /22, /23, /24, /25 and /27.
For insert arrangements: See MIL-STD-1560.
Lanyard:
a. 1.57 millimeter diameter, seven strands of stainless steel capable of withstanding
890 Newton pull test after assembly with connector.
b. Cable shall be covered with a suitable protective sleeving to preclude possible chafing or
abrading of wires.
Connector shall disengage from any coupling condition including partially mated.
Connector design shall incorporate a swivel action for the lanyard to prevent twisting of the cable.
Part or Identifying Number (PIN) example:
D38999/
30
W
B
35
E
N
DOD number prefix
Specification sheet number
Class
Shell size code
Insert arrangement
Lanyard length code (see table I)
Polarizing positions
N is required for normal position
Class F is not for Navy use and is inactive for Air Force new design use.
NOTE: The term PIN is equivalent to the term (part number, identification number, and type
designator) which was previously used in this specification.
3
