MIL-DTL-39024/10E
TABLE I. Design and identification data.
Insulation
Dash
Supersedes
Style
Number in
number
MS16108
Color
accordance with
FED-STD-595
-01
-1A, -11A, -12A
White
17875
-02
-2A
Red
11105
-03
-3A
Black
17038
-04
-4A
Brown
10075
-05
-5A
Green
14110
-06
-6A
Turret
Orange
12246
-07
-7A
Blue
15123
-08
-8A
Yellow
13655
-09
-9A
Gray
16187
-10
-10A
Purple
27144
-11
-1C, -11C, -12C
White
17875
-12
-2C
Red
11105
-13
-3C
Black
17038
-14
-4C
Brown
10075
-15
-5C
Eyelet
Green
14110
-16
-6C
Orange
12246
-17
-7C
Blue
15123
-18
-8C
Yellow
13655
-19
-9C
Gray
16187
-20
-10C
Purple
27144
REQUIREMENTS:
Design and construction:
Dimensions and configuration: See figure 1 and table I.
Insulation: Material shall be polyamide in accordance with L-P-410 or ASTM D4066.
Terminals: Shall be capable of being wired with two type E, AWG 20 wires in accordance with
NEMA-HP3.
Metals and finishes: Shall conform to requirements of MIL-DTL-39024, except that the minimum
nickel plating thickness for copper and copper alloys, except for contacts and terminals, shall be
.0002 inch.
Test probe: 0.080 ± 0.001 inch in diameter and ½ -inch (min) length.
Contact current rating: 5 amperes (max).
Contact resistance: A test probe in accordance with MIL-DTL-39024 shall be fully inserted into the
connector.
Test current: 5 amperes.
Points of measurement: Between the connector terminal and the extreme end of the solder cup on
the test probe.
