MIL-DTL-39024/10E
Measured values: See table II.
Dielectric withstanding voltage (at sea level):
Test voltage: 3,000 volts rms, 60 hertz, shall be applied to insulating material for a period of 15
seconds.
Insertion and withdrawal forces:
Insertion force: 5.0 pounds (max).
Withdrawal force: 0.4 pounds (min).
Durability: One thousand insertion-withdrawal cycles shall be performed. After the tests, connectors
shall meet the initial measurements of insertion and withdrawal force, and contact resistance in
table II.
TABLE II. Potential drop (max) with 5 amperes of current.
Test
Voltage drop (max)
Initial
6 mV
After durability
8 mV
After vibration
10 mV
After salt spray (corrosion)
15 mV
Operating conditions:
Operating voltage: 2,000 volts rms, 60 hertz at sea level; 350 volts rms, 60 hertz at 80,000 feet.
Note: Marginal notations are not used in this revision to identify changes with respect to the previous
issue due to the extent of the changes.
CONCLUDING MATERIAL
Custodians:
Preparing activity:
Army - CR
DLA - CC
Navy - EC
Air Force - 11
(Project 5935-4438-001)
DLA - CC
Review activities:
Army - AR, CR4, EA, MI
Navy - AS, CG, MC, OS
Air Force - 19
