MIL-DTL-39024/13D
TABLE I. Design and identification data.
1/
Insulation
Dash
Dimensions (inches)
number
A .010 (0.25)
B .015 (0.38)
C .015 (0.38)
Color
Number in accordance with
FED-STD-595/
-01
.300 (7.62)
0.060 (1.52)
0.218 (5.54)
White
17875
-02
"
"
"
Red
11105
-03
"
"
"
Black
17038
-04
"
"
"
Brown
10075
-05
"
"
"
Green
14110
-06
"
"
"
Orange
12246
-07
"
"
"
Blue
15123
-08
"
"
"
Yellow
13655
-09
"
"
"
Gray
16187
-10
"
"
"
Purple
27144
-11
"
"
"
Natural
---
-12
.400 (10.16)
.025 (0.64)
.175 (4.45)
White
17875
-13
"
"
"
Red
11105
-14
"
"
"
Black
17038
-15
"
"
"
Brown
10075
-16
"
"
"
Green
14110
-17
"
"
"
Orange
12246
-18
"
"
"
Blue
15123
-19
"
"
"
Yellow
13655
-20
"
"
"
Gray
16187
-21
"
"
"
Purple
27144
-22
"
"
"
Natural
---
1/ Dimensions are in inches. Metric equivalents are given for information only.
REQUIREMENTS:
Design and construction:
Dimensions and configuration: See figure 1 and table I.
Insulation: Material shall be polyamide in accordance with L-P-410 or ASTM D4066.
Flammability: Dielectric materials shall be self-extinguishing in accordance with ASTM D635.
Test probe: 0.080 0.001-inch diameter and .450 inch (min) length. Test probe shall be engaged a
minimum of .450 inches. Test probe shall be fully inserted.
Contact current rating: 5 amperes (maximum).
Contact sleeve: Shall be formed of strip to make a cylinder with a butted seam.
Contact resistance: A test probe in accordance with MIL-DTL-39024 shall be fully inserted in the
connector. With a current of 5 amperes, potential drop shall be measured between the connector
terminal and the extreme end of the solder cup on the test probe. Measured values shall be within the
limits specified in table II.
