MIL-DTL-39024/14C
TABLE I. Design and identification data.
Insulation
Dash
number
Material
Color
Number in
accordance
with FED-STD-595/
-01
White
17875
-02
Red
11105
-03
Black
17038
-04
Brown
10075
-05
Green
14110
-06
L-P-410
Orange
12246
-07
or
Blue
15123
-08
ASTM D4066
Yellow
13655
-09
Gray
16187
-10
Purple
27144
-11
Natural
----
-12
White
17875
11105
-13
Red
17038
-14
Black
10075
-15
Brown
14110
-16
ASTM D1710
Green
12246
-17
Orange
15123
-18
Blue
13655
-19
Yellow
16187
-20
Gray
27144
-21
Purple
----
-22
Natural
REQUIREMENTS:
Design and construction:
Dimensions and configuration: See figure 1.
Insulation: Material shall be as specified in table I.
Socket contact and terminals: Material shall be as specified in MIL-DTL-39024.
Flammability: Dielectric materials shall be self-extinguishing in accordance with ASTM D635.
Terminals: Shall be capable of being wired with two no. 20 AWG wires. Configuration shall be specified
on figure 1.
Test probe: 0.080 ± 0.001 inch in diameter and ½ -inch (min) length. Test probe shall be engaged for a
minimum of ½ inch.
Contact current rating: 5 amperes (max).
Contact resistance: A test probe in accordance with MIL-DTL-39024 shall be fully inserted in the
connector. With a current of 5 amperes, potential drop shall be measured between the connector
terminal and the extreme end of the solder cup on the test probe. Measured values shall be within the
limits specified in table II.
2
