MIL-DTL-39024/14C
TABLE II. Potential drop (max) with 5 amperes of current.
Test
Before test
After test
Durability
6 mV
8 mV
Vibration
8 mV
10 mV
Salt spray (corrosion)
10 mV
15 mV
Dielectric withstanding voltage (at sea level):
Test voltage: 3,000 volts rms, 60 hertz, shall be applied to the insulting material for period of 15
seconds.
Insertion and withdrawal forces:
Insertion force: 5.0 pounds (max).
Withdrawal force: 0.4 pound (min).
Identification marking:
Part or Identifying Number (PIN): M39024/14-(dash number from table I).
Operating conditions:
Operating voltage: 2,000 volts rms, 60 hertz at sea level; 350 volts rms, 60 hertz at 80,000 feet.
The thickness of the panel on which these connectors may be used ranges from 0.031 to 0.093 inch;
the diameter of the mounting hole is 0.218 ± 0.001 inch.
Qualification: Not applicable.
Conformance inspection. Groups A and B tests in accordance with MIL-DTL-39024 shall be
applicable.
Changes from previous issue. The margins of this specification are marked with vertical lines to indicate
where changes from the previous issue were made. This was done as a convenience only and the
Government assumes no liability whatsoever for any inaccuracies in these notations. Bidders and
contractors are cautioned to evaluate the requirements of this document based on the entire content
irrespective of the marginal notations and relationship to the last previous issue.
Referenced documents. In addition to MIL-DTL-39024, this document references the following:
ASTM D635
FED-STD-595/14110
ASTM D1710
FED-STD-595/15123
ASTM D4066
FED-STD-595/16187
FED-STD-595/10075
FED-STD-595/17038
FED-STD-595/11105
FED-STD-595/17875
FED-STD-595/12246
FED-STD-595/27144
FED-STD-595/13655
L-P-410
