MIL-DTL-55181/8D
REQUIREMENTS:
Dimensions and configuration: See figures 1 and 2, and table I.
Contacts: 7.5 ampere current rating, 20 AWG.
Mating connectors: M55181/7-01, M55181/7-02, M55181/7-03, M55181/7-04, and M55181/7-05.
Part or Identifying Number (PIN): M55181/8 (dash number specified in table I).
Supersession, cross-reference and mating connectors: See table II.
TABLE I. PIN.
PIN
M55181/8-01
Without grounding washer
M55181/8-01W
With grounding washer
TABLE II. Supersession, cross reference and mating connector.
PIN
Old type designator 1/
Mating type designator 1/
M55181/8-01
MW20F(M)D00
MW10M(M)D11
M55181/8-01
MW20F(M)D00
MW10M(M)D13
M55181/8-01
MW20F(M)D00
MW10M(M)D17
M55181/8-01
MW20F(M)D00
MW10M(M)D19
M55181/8-01
MW20F(M)D00
MW10M(M)D15
1/ This type designator shall not be referenced for procurement purposes.
Changes from previous issue. The margins of this specification are marked with vertical lines to indicate
where changes from the previous issue were made. This was done as a convenience only and the
Government assumes no liability whatsoever for any inaccuracies in these notations. Bidders and
contractors are cautioned to evaluate the requirements of this document based on the entire content
irrespective of the marginal notations and relationship to the last previous issue.
Referenced documents: In addition to MIL-DTL-55181, this document references the following:
SAE-AMS-2700
