MIL-DTL-55302/124A
Pin, roll, key retaining.
(SEE NOTE 6)
A ± .010
KEY/PIN
M55302/124-01
.250
M55302/124-02
.312
(SEE NOTE 6)
Key
Inches
mm
.001
.02
.002
.05
.003
.08
.004
.10
.010
.25
.015
.38
.025
.64
.034
.86
.042
1.07
.043
1.09
.080
2.03
.086
2.18
.093
2.36
.106
2.69
.187
4.75
.200
5.08
.205
5.21
.250
6.35
.312
7.92
.325
8.26
FIGURE 1. Key assembly Continued.
