MIL-DTL-55302/128D
TABLE II. Printed circuit board and plating thickness.
Code
Board
Y
Contact
Remainder
thickness
dimension
area
plating
plating
thickness
thickness
A
.062
.115
Class 1
Flash
B
.062
.115
Class 1
Class 1
C
.093
.145
Class 1
Flash
D
.093
.145
Class 1
Class 1
E
.125
.175
Class 1
Flash
F
.125
.175
Class 1
Class 1
G
.062
.115
Class 1
Tin/lead dipped or plated
H
.093
.145
Class 1
Tin/lead dipped or plated
I
.125
.175
Class 1
Tin/lead dipped or plated
Inches
mm
.0020
0.051
.005
0.13
.0085
0.216
.020
0.51
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
FIGURE 2. Mating post tip configuration.
