MIL-DTL-55302/128D
Dielectric withstanding voltage:
Sea level: 750 volts rms.
High altitude: 275 volts rms.
Contact bend test: The body of the contact shall be slowly inclined so as to bend the contact through
90° and then return it to the original position. A bend through 90° and return to original position shall
be defined as one bend. The test shall include three bending cycles.
PIN example:
AB
2
C
M55302/128-
Military designator
Specification sheet
Number of contacts
(see table I)
P.C. board type
(see table II)
Plating code
(see table II)
Changes from previous issue. Marginal notations are not used in this revision to identify changes with
respect to the extent of the changes.
Referenced documents. In addition to MIL-DTL-55302, this document references the following:
ASTM D4066
IPC-D275
8
