MIL-DTL-55302/130D
Inches
mm
Inches
mm
Inches
mm
.003
0.08
.072
1.83
.225
6.35
.005
0.13
.075
1.91
.250
6.48
.006
0.15
.080
2.03
.275
6.99
.010
0.25
.082
2.08
.365
9.27
.014
0.36
.096
2.44
.425
10.80
.015
0.38
.100
2.54
.450
11.43
.019
0.48
.101
2.57
.495
12.57
.020
0.51
.105
2.67
.675
17.15
.022
0.56
.109
2.77
7.900
200.66
.025
0.64
.113
2.87
8.024
203.81
.034
0.86
.125
3.18
8.450
214.63
.035
0.89
.180
4.57
8.750
222.25
.039
0.99
.195
4.95
8.780
223.01
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. Unless otherwise specified, tolerances are ±.005 (0.13 mm) on decimals and ±2º.
4. These connectors mate with connectors specified in MIL-DTL-55302/129.
5. Use printed circuit boards with both the type 1 and type 2 receptacles.
6. Numbers indicating end cavities and letters indicating rows marked or molded this surface.
7. Locations indicators embossed on surface.
8. Lines indicate every five cavities marked or molded on mating face except end cavities.
FIGURE 1. Connectors, kit receptacle, .100 (25.4 mm) spacing, 160 and 240 contacts - Continued.
4
