MIL-DTL-55302/140C
Crimping tools:
Basic tool: M22520/2-01.
Positioner: M22520/2-36.
Hood types: See MIL-DTL-55302/155.
Mounting hardware: See MIL-DTL-55302/154, figure 2, plug.
Mating connectors: Shall be in accordance with MIL-DTL-55302/142.
Part or Identifying Number (PIN): Consists of the letter M, the basic number of the specification sheet,
and a dash number compiled as follows:
Example:
*
*
N
1
*
M55302/140
Specification sheet number
Plug with pin contacts
Contact arrangement
(see figure 3)
Contact type 2.5 amperes
(see figure 4)
Contact type Coaxial
N not applicable
Indexing type
1 Hexagon post (36 positions)
Mounting hardware
(see MIL-DTL-55302/154)
Changes from previous issue. Marginal notations are not used in this revision to identify changes with
respect to the previous issue due to the extent of the changes.
Referenced documents. In addition to MIL-DTL-55302, this document references the following:
MIL-DTL-55302/142
MIL-DTL-55302/154
MIL-DTL-55302/155
8
