MIL-DTL-55302/161D
Contact retention minimum: Functional value 22.2 newtons (5 pounds); destructive test 35.3
newtons (8 pounds) maximum design and qualification value.
Contact rating: 5 amperes per line.
Durability: 2,000 cycles minimum.
Dielectric withstanding voltage:
Sea level: 1,400 V ac rms test.
High altitude: 300 V ac rms test.
Keying: Rotation of guides, 6 positions each, 36 possible combinations.
Connector Part or Identifying Number (PIN):
161
J
160
B
Example:
D55302/
Specification number
Specification sheet number
Type of contact and termination
(see figures 1 and 2)
Number of contacts
(see table I)
Guide hardware number
(see figure 3 and table I)
Changes from previous issue. Marginal notations are not used in this revision to identify changes with
respect to the previous issue due to the extent of the changes.
Referenced documents. In addition to MIL-DTL-55302, this document references the following:
MIL-DTL-55302/164
ASTM B36
ASTM B488
MIL-STD-202
ASTM B124
ASTM D5948
ASTM A582
ASTM B453
SAE-AMS-QQ-N-290
ASTM B16
ASTM B455
SAE-AMS-QQ-P-35
