MIL-DTL-55302/163D
TABLE I. Number of contacts.
Dimension (in millimeters)
Number
of
A
B
contacts
72
106.7
114.7
84
121.9
129.9
96
137.2
145.2
120
167.6
175.5
TABLE II. Mating references.
Type
Will only mate with
Locking method
(see note)
B
P, U, W
None
F
J, K
Push 1/4 turn
G
J, K
Push 1/4 turn
J
F, G
Push 1/4 turn
P
B, T, V
None
T
P, U, W
None
U
B, T, V
None
V
P, U, W
None
W
B, T, V
None
X
Z
Screw
Z
X, Y
Screw
NOTE: These connectors mate with MIL-DTL-55302/160.
TABLE III. Mounting references.
Number of
A
contacts
72
106.70
84
121.90
96
137.20
120
167.60
13
