MIL-DTL-55302-164 Connectors, Printed Circuit Subassembly And Accessories, Plug And/Or Receptacle, 160 Contact Positions, For Printed Wiring Boards, 2.54 Mm X 1.27 Mm Offset Grid, Metric

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15 - 16 - 17 - 18 - 19 - 20 - 21


MIL-DTL-55302/164D
TABLE I. Mating references.
Type
Will only mate with
Locking method
(see note)
B
P, U, W
None
F
J, K
Push 1/4 turn
G
J, K
Push 1/4 turn
J
F, G
Push 1/4 turn
P
B, T, V
None
T
P, U, W
None
U
B, T, V
None
V
P, U, W
None
W
B, T, V
None
X
Z
Screw
Z
X, Y
Screw
NOTE: These connectors mate with MIL-DTL-55302/160.
