MIL-DTL-55302/168C
TABLE I. Indicators and dimensions Continued.
2 Contact rows
3 Contact rows
4 Contact rows
Dimensions 1/ 2/
Indicator
Total
Indicator
Total
Indicator
Total
+ .004
3/
3/
3/
contacts
contacts
contacts
A Max
B
K - .006
A39
78
B39
117
C39
156
5.195
4.875
4.015
(131.95)
(123.83)
(101.98)
A40
80
B40
120
C40
160
5.295
4.975
4.115
(134.49)
(126.37)
(104.52)
A42
82
B41
123
C41
164
5.395
5.075
4.215
(137.03)
(128.91)
(107.06)
A42
84
B42
126
C42
168
5.495
5.175
4.315
(139.57)
(131.45)
(109.60)
A43
86
B43
129
C43
172
5.595
5.275
4.415
(142.11)
(133.99)
(112.14)
A44
88
B44
132
C44
176
5.695
5.375
4.515
(144.65)
(136.53)
(114.68)
A45
90
B45
135
C45
180
5.795
5.475
4.615
(147.19)
(139.07)
(117.22)
A46
92
B46
138
C46
184
5.895
5.575
4.715
(149.73)
(141.61)
(119.76)
A47
94
B47
141
C47
188
5.995
5.675
4.815
(152.27)
(144.15)
(122.30)
A48
96
B48
144
C48
192
6.095
5.775
4.915
(154.81)
(146.69)
(124.84)
A49
98
B49
147
C49
196
6.195
5.875
5.015
(157.35)
(149.23)
(127.38)
A50
100
B50
150
C50
200
6.295
5.975
5.115
(159.89)
(151.77)
(129.92)
A51
102
B51
153
C51
204
6.395
6.075
5.215
(162.43)
(154.31)
(132.46)
A52
104
B52
156
C52
208
6.495
6.175
5.315
(164.97)
(156.85)
(135.00)
A53
106
B53
159
C53
212
6.595
6.275
5.415
(167.51)
(159.39)
(137.54)
A54
108
B54
162
C54
216
6.695
6.375
5.515
(170.05)
(161.93)
(140.08)
A55
110
B55
165
C55
220
6.795
6.475
5.615
(172.59)
(164.47)
(142.62)
A56
112
B56
168
C56
224
6.895
6.575
5.715
(175.13)
(167.01)
(145.16)
A57
114
B57
171
C57
228
6.995
6.675
5.815
(177.67)
(169.55)
(147.70)
A58
116
B58
174
C58
232
7.095
6.775
5.915
(180.21)
(172.09)
(150.24)
A59
118
B59
177
C59
236
7.195
6.875
6.015
(182.75)
(174.63)
(152.78)
A60
120
B60
180
C60
240
7.295
6.975
6.115
(185.29)
(177.17)
(155.32)
A61
122
B61
183
C61
244
7.395
7.075
6.215
(187.83)
(179.71)
(157.86)
A62
124
B62
186
C62
248
7.495
7.175
6.315
(190.37)
(182.25)
(160.40)
A63
126
B63
189
C63
252
7.595
7.275
6.415
(192.91)
(184.79)
(162.94)
A64
128
B64
192
C64
256
7.695
7.375
6.515
(195.45)
(187.33)
(165.48)
A65
130
B65
195
C65
260
7.795
7.475
6.615
(197.99)
(189.87)
(168.02)
A66
132
B66
198
C66
264
7.895
7.575
6.715
(200.53)
(192.41)
(170.56)
See footnotes at end of table.
