MIL-DTL-55302/180C
F ± .015 (0.38 mm)
Type
Type of termination
Inches
mm
.180
4.57
I
Solder post (see note 8)
.120
3.05
IV
Inches
mm
Inches
mm
.002
0.05
.150
3.81
.005
0.13
.170
4.32
.006
0.15
.182
4.62
.010
0.25
.200
5.08
.015
0.38
.213
5.41
.042
1.07
.275
6.98
.050
1.27
300
7.62
.054
1.37
.434
11.02
.070
1.78
.465
11.81
.080
2.03
.604
15.34
.100
2.54
.819
20.80
.120
3.05
.846
21.49
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. Unless otherwise specified, tolerance is ± .005 (0.13 mm) on decimals and ± 2° on angles.
4. These connectors mate with connectors specified in MIL-DTL-55302/179 and /181.
5. Location indicators embossed on surface.
6. Numbers indicating end cavities, letters indicating row nearest to polarizing feature, and markings every
ten positions stamped on this surface.
7. Chamfers shall be .015 (0.38 mm) minimum at a 45° angle ± 5°.
8. Solder post shall be a .036 (0.91 mm) maximum diameter or .036 (0.91 mm) maximum across the diagonal.
FIGURE 1. Connectors, receptacle assemblies .100 (2.54 mm) spacing 100 through 300 contacts Continued.
