MIL-DTL-55302/182C
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. Unless otherwise specified, tolerance is ± .005 (0.13 mm).
FIGURE 2. Guide pin, M55302/182-01, -02, and 03.
Inches
mm
Guide pin number
A
Figure
.050
1.27
.080
2.03
2
.475
M55302/182-01
.086
2.18
2
.562
M55302/182-02
.180
4.57
2
.750
M55302/182-03
.475
12.06
3
.475
M55302/182-04
.562
14.27
3
.562
M55302/182-05
.650
16.51
3
.750
M55302/182-06
.750
19.05
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. Unless otherwise specified, tolerance is ± .005 (0.13 mm).
FIGURE 3. Guide pin kit, M55302/182-04, -05, and 06.
2
