MIL-DTL-55302/57H
Inches
mm
Inches
mm
Inches
mm
.001
0.03
.020
0.51
.075
1.91
.002
0.05
.025
0.64
.078
1.98
.005
0.13
.027
0.69
.082
2.08
.006
0.15
.028
0.71
.086
2.18
.008
0.20
.030
0.76
.094
2.39
.010
0.25
.032
0.81
.100
2.54
.015
0.38
.051
1.30
.107
2.72
Dimensions
Number
of
A
BSC
REF
BSC
E
contacts
±.010
B
C
D
±.010
10
.850
.650
.400
1.100
1.350
(21.59)
(16.51)
(10.16)
(27.94)
(34.29)
14
1.050
.850
.600
1.300
1.550
(26.67)
(21.59)
(15.24)
(33.02)
(39.37)
20
1.350
1.150
.900
1.600
1.850
(34.29)
(29.21)
(22.86)
(40.64)
(46.99)
24
1.550
1.350
1.100
1.800
2.050
(39.37)
(34.29)
(27.94)
(45.72)
(52.97)
26
1.650
1.450
1.200
1.900
2.150
(41.91)
(36.83)
(30.48)
(48.26)
(54.61)
30
1.850
1.650
1.400
2.100
2.350
(46.99)
(41.91)
(35.56)
(53.34
(56.69)
36
2.150
1.950
1.700
2.400
2.650
(54.61)
(49.53)
(43.18)
(60.96)
(67.31)
40
2.350
2.150
1.900
2.600
2.850
(56.69)
(54.61)
(48.26)
(66.04)
(72.39)
44
2.550
2.350
2.100
2.800
3.050
(64.77)
(56.69)
(53.35)
(71.12)
(85.09)
50
2.850
2.650
2.400
3.100
3.350
(72.39)
(67.31)
(60.96)
(78.74)
(85.09)
54
3.050
2.850
2.600
3.300
3.550
(85.09)
(72.39)
(66.04)
(83.82)
(90.17)
56
3.150
2.950
2.700
3.400
3.650
(80.01)
(74.93)
(68.58)
(86.36)
(92.71)
60
3.350
3.150
2.900
3.600
3.850
(85.09)
(80.01)
(73.66)
(91.44)
(97.79)
66
3.650
3.450
3.200
3.900
4.150
(92.71)
(87.63)
(81.28)
(99.06)
(105.41)
70
3.850
3.650
3.400
4.100
4.350
(97.79)
(92.71)
(86.36)
(104.14)
(110.49)
FIGURE 1. Connectors, plug, .100 (2.54 mm) spacing - Continued.
