MIL-DTL-55302/7E
Inches
mm
Inches
mm
Inches
mm
.002
0.05
.039
0.99
.080
2.03
.004
0.10
.044
1.12
.187
4.75
.005
0.13
.050
1.27
.200
5.08
.007
0.18
.055
1.40
.202
5.13
.008
0.20
.059
1.50
.208
5.28
.009
0.23
.060
1.52
.340
8.64
.012
0.30
.065
1.65
.345
8.76
.026
0.66
.069
1.75
.350
8.89
.028
0.71
.070
1.78
.355
9.02
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. Unless otherwise specified, tolerances are ± .005 (0.13 mm) on three place decimals and ± 2° on angles.
4. These connectors mate with connectors in accordance with MIL-DTL-55302/8 and are primarily for use with
multilayered printed wiring boards.
5. Positional tolerances of guide pins shall apply at datum plane X.
6. Pad(s) suitable for printed circuit board support are required. Dimensions and location(s) are optional.
7. The terminating side and the side opposite mating face of the plug may be open or solid construction.
FIGURE 1. Connectors, plug (.100 spacing) - Continued.
